Appendix M, Add/Remove Node from RPR Ring - Add Node to a Complete Ring
65K510DEP08-1A M-5
Figure M-4. Current West Protection Menu
FigureM‐5displaysanexampleofaManualSwitch.
Figure M-5. Protection Command: Manual
2. OncetheManualSwitch completes, gobacktotheIdlecondition.Allow10secondsto
pass,andperformaForcedSwitchontheEastInterface.
3. LogontoNodeBandperformaForcedSwitchontheWestInterface.
4. Disconnectthe
fibersbetweenNodeBandC.
TID: TA5000 Total Access 5000 System MM/DD/YY hh:mm
Unacknowledged Alarms: None Node: 1
Current West Protection: Idle
1. Force Switch
2. Manual Switch
3. Idle
Selection : 2
W-West E-East
'?' - System Help Screen
TID: TA5000 Total Access 5000 System MM/DD/YY hh:mm
Unacknowledged Alarms: None Node: 1
RPR Provisioning
1. Keepalive Timeout (ms) : 5
2. Wait to Restore Time (s) : 10
West East
3. Protection Holdoff Time (ms): 0 0
4. Protection Command : Manual Switch Idle
5. Fairness Weight : 1 1
6. Reset Watermarks
Selection :
'?' - System Help Screen
