ADTRAN Total Access 5000 Deployment Guide

Section 3, Common Provisioning - Configure SCM Management
65K510DEP08-1A 3-15
NOTE
Thegatewayshouldbetheroutertowhichtheinterfaceis connected,orthe
firstrouti nghopoutsideoftheTotalAccess5000fortheinterface.Astatic
entryforthe gatewayis added tothe route table when thegatewayis
configured,andthatIP addressisusedasthefirst
hopforroutingonthat
interface.
9. Type
exit,andpressENTERtoreturntotheEnableprompt.
Provisioning the Ethernet Interface
TosettheEthernetinterfacefortheshelf,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface ethernet 1/S/1,andpress
ENTERtoaccesstheEthernetInterfaceConfigurationprompt.
3. FromtheEthernetInterfaceConfigurationprompt,type
ip address A.B.C.D
A.B.C.D
,andpressENTERtoconfiguretheEthernetinterfaceIPaddressandsubnet
mask.
4. FromtheEthernetConfigurationprompt,type
no shutdown,andpressENTERtoreturn
toenabletheEt hernetInterfaceConfigurationprompt.
5. Type
exit,andpressENTERtoreturntotheGlobalConfigurationprompt.
6. FromtheGlobalConfigurationprompt,type
ip route A.B.C.D A.B.C.D A.B.C.D,
andpressEntertosetthegatewayfortheEthernetinterface,wherethefirstvalueisthe
IPaddressoftheEthernetinterface,thesecondvalueisthesubnetmask,andthethird
valueisthegatewayIPaddressfortheEthernetinterface.
NOTE
Thegatewayshouldbetheroutertowhichtheinterfaceis connected,orthe
firstrouti nghopoutsideoftheTotalAccess5000fortheinterface.Astatic
entryforthe gatewayis added tothe route table when thegatewayis
configured,andthatIP addressisusedasthefirst
hopforroutingonthat
interface.
7. Type
end,andpressENTERtoreturntotheEnableprompt.
NOTE
IfboththeIn ban dandEthernetinterfaceIPaddressesareprovisionedand
enabled,theymustbeondifferentsubnets.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
