ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
G-6 65K510DEP08-1A
NOTE
Valid<command_type>valuesarecsu,fdl,andfeac.
•Type
no remote-loopback,andpressENTERtoprovisiontheporttoignoreremote
loopbackcommands.
NOTE
Valid<command_type>valuesarecsu,fdl,andfeac.
4. FromtheT1InterfaceConfigurationprompt,type
end,andpressENTERtoreturntothe
Enableprompt.
Test Administrative Functions
TheTotalAccess5000CLIApplicationprompt,controlsboththelocalloopbackandBERT
functions.WhileintheApplicationprompt,thefollowingcommandscanbeissued:
•ViewthecurrentteststatusoftheDS3interfacebytyping
show test interface t1
<shelf/slot/port:channel>
,andpressENTER
•CleartheteststatisticsoftheDS3interfacebytypingtest interface t1
<shelf/slot/port:channel> clear
,andpressENTER
•Stopanytestinprogress(loopbackorBERT)bytypingno test interface t1
<shelf/slot/port:channel>
,andpressENTER
Local Line Loopback Configuration
ToconfigurelocalDS3loopbacks,completethefollowingsteps:
1. FromtheEnableprompt,type
application,andpressENTERtoaccesstheApplication
prompt.
2. FromtheApplication prompt,type
test interface t1 <shelf/slot/
port:channel> local loopback line timeout <0-9999>
,andpressENTERtostart
aDS1lineloopback.
NOTE
•Theloopbacktimeoutisoptionalandcanbeleftofftheloopbackcommand
NOTE
•TheDS3lineloopback canbestoppedbytypingno test interface t1
<shelf/slot/port:channel>,andpressENTER
BERT Test Configuration
TheChannelizedDS3Multi‐Service3‐PortperformsBERTgenerationandtestingattheDS3
interfaces.ToconfiguretheDS3BERT,completethe followingsteps:
1. FromtheEnableprompt,type
application,andpressENTERtoaccesstheApplication
prompt.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
