ADTRAN Total Access 5000 Deployment Guide

Section 6, EoTDM Provisioning - Provisioning Summary
65K510DEP08-1A 6-3
Provisioning Summary
TocreateadatapathfromtheGigESMportontheTotalAccess5000toanEthernetporton
theNetVanta800,completethefollowing:
1. ProvisiontheDS3EFM4‐PortorDS3EFM3‐PortLineModule.
Formoreinformation,referto“ProvisiontheLineModule”onpage 6‐4.
2. Create
anEFMbondinggroupattheGigESMthatbondsasetofDS3portsontheDS3
EFMlinemoduletogether.
ThebondinggroupactsasthedataflowaccesspointtotheNetVanta800andisthepath
downwhichthemanagementconfigurationispushed.
Formoreinformation,refer
to“CreateanEFMBondingGroup”onpage 6‐6.
3. CreateanEthernetVirtualCircuit(EVC)attheTotalAccess5000thatconnectstheEFM
grouptotheGigabitEthernetportoftheGigESM.
ThiscreatesthemappingoftheS‐taggeddata.Thisaccomplishesthefollowing:
•TheGigESMknowswhere
tosendthetaggedtrafficcominginfromthegigabit
networkport
•TheGigESMpushestheavailabletagstoeachEFMbondinggroupandtoeach
NetVanta800forthelocalNetVanta800provisioning
4. LogontotheNetVanta800.
Formoreinformation,referto“LogOntotheNetVanta800”
onpage 6‐16.
5. CreatetheEVCattheNetVanta800.
TheEVCisalogicalconnectionpointintotheEFMgroup.
NOTE
•MultipleEVCscanbecreatedforagivenEFMgroup.
•FortheNetVant a,theshelfisalways1andtheslotisalwayszero.
Formoreinformation,referto“CreateanEVC”onpage 6‐17.
6. CreateamapattheNetVanta800thatinformstheunittoswitchdatafromagivenUser
toNetworkInterface(UNI),ataminimum,to
aparticularEVC,andviceversa.
Formoreinformation,referto“CreateanEVCMap”onpage 6‐20.
7. ProvisionMACAddressLimitingandAging.
Forformoreinformation,referto“ProvisionMACAddressLimitingandAging”on
page 6‐27.
8. Disableanyunusedinterfaces.
Formoreinformation,referto“DisableUnusedNetVanta800
Interfaces”onpage 6‐28.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
