ADTRAN Total Access 5000 Deployment Guide

Section 6, EoTDM Provisioning - Create an EVC
65K510DEP08-1A 6-17
Create an EVC
Thissectiondetailsthefollowinginformation:
• DefinitionofanEVC
•EVCguidelines
•StepsforcreatinganEVC
•StepsforconfiguringanEVC
•EVCexample
EVC Definition
TheMetroEthernetForum(MEF)definesanEVCas“anassociationoftwoormoreUNIs,”
whereaUNIisastandard10/100/1000 Ethernetinterfacethatisthepointofdemarcation
betweenthe CustomerEquipment(CE)andtheMetroEthernetNetwork(MEN)oftheservice
provider.Insimpleterms,anEVC
performstwofunctions.
• Connectstwoormoresubscribersites(UNIs)enablingthetransferofEthernetservice
frames
•PreventsdatatransferbetweenthesubscribersitesthatarenotpartofthesameEVC
ThiscapabilityenablesanEVCtoprovidedataprivacyandsecuritysimilartoaFrameRelay
orATMPermanentVirtual
Circuit(PVC).
MultipleEVCscanresideonacommonbondinggrouporEthernetport.EachEVCtypically
hasanassociatedEVCVLANtagwhoseVLANIDisuniqueamongotherEVCsintheMEN.
TheEVCVLANtagallowstheEVCtobeidentifiedandsepara tedfromotherEVCs.
Ata
minimum,twoitemsmustbesetupfortheEVC:theMENportitwilluseandtheS‐tagit
willuse.
NOTE
TheS‐tagmustmatchtheEVCsconfiguredattheTotalAccess5000.
EVC Guidelines
Toensurevalidprovisioning,enforcethefollowingguidelineswhencreatinganEVC:
•AnEVCisappliedonlyifthe statusisRunning(asindicatedinthe
show evcoutput),
whichindicatesthattheconditionsarevalid
•TwoEVCsareconsideredtobeduplicateiftheybothhavethesamevaluesforthe
followingattributes:
–MENport
–S‐tag
•NotwoEVCscanhavethesamename
•IfthesystemismanagedthroughaVLANonadesignatedbondinggrouporEthernet

port,theS‐tagvaluefortheEVCcannotequalthemanagementVLANID

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
