ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
5-6 65K510DEP08-1A
Provision the DS1 PPP/MLPPP 32-Port Line Module Adminis-
tration Status
TheDS1PPP/MLPPP32‐PortLineModulecardservicestatemustbesettoInService,Outof
Service,orOutofService‐Maintenance.
NOTE
•IfthecardservicestateissettoOutofService‐Maintenance,normal
operationoccursbutalarmsarenotreported.
•LinecodeandlinebuildoutcannotbeprovisionedforDS1.
Fortraffictopass,theDS1PPP/MLPPP32‐PortLineModulemustbeenabled.
Table5‐2displaysthethreeadministrationstatesandshowstheequivalentServiceStatefrom
priorreleases.
Tosetthemoduleadministrationandportadministrationstates,complete
thefollowing
procedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
NOTE
Ifconnectedto the shelfwherethemoduleresides,theshelfnumberis
typically1.
2. FromtheGlobalConfigurationprompt,provisionthemoduleadministrationstateby
performingoneofthefollowingcommands:
•Type
no slot shutdown <shelf/slot>,andpressENTERtotakeaslotInService
•Type
slot shutdown maintenance <shelf/slot>,andpressENTERtotakeaslot
OutofServiceMaintenance
•Type
slot shutdown <shelf/slot>,andpressENTERtotakeaslotOutofService,
Unassigned
3. FromtheGlobalConfigurationprompt,type
interface t1 <shelf/slot/port>,and
press
ENTER.
Table 5-3. DS1 Administration States
Command Previous Description
no shutdown
InService
Inthe no shutdownstate,trafficpasses
andalarmsaregenerated.
shutdown maintenance
OutofService,
Maintenance
Intheno shutdownstate,trafficpasses
butnoalarmsaregenerated.Alarmsare
suppressedandnoevidenceofthealarm
isshown.
shutdown
OutofService,
Unassigned
Inthe no shutdownstate,notraffic
passesandnoalarmsaregenerated.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
