Section 6, EoTDM Provisioning - Create an EVC Map

65K510DEP08-1A 6-21

Provisioning Steps

Tocreatethemap,completethefollowing:

1. FromtheEnableprompt,type

configure terminal,andpressENTERtoaccesstheGlo‐

balConfigurationprompt.

2. FromtheGlobalConfigurationprompt,type

evc-map WORD,andpressENTERtocreate

themapandenterthemapconfigurationmode.

Thisattributeisanarbitrarystringthatisusedtoidentifythemap.Thevaluemustbe

uniqueacrossallmapsdefinedintheproductandisintendedformanagementand

controlpurposes.Thevalueisnotcarriedinanyfield

intheEthernet frame.

Configure the Map

TheUsertoNetworkInterface(UNI)andtheEVCmustbeconfiguredforthemap.Amap

bindstheUNItraffictotheEVC.Toconfigurethemap,completethefollowing:

1. FromtheEVC‐MapConfigurationprompt,settheUNIbytypingeither

connect uni

ethernet

orconnectuni gigabit-ethernetfollowedbytheethernetportnumber

in

1/0/portformat,andpressENTER.

TheWORDattributeisthephysicalinterfaceconnectedtothecustomerequipment.The

possibleoptionsconsistoftheEthernetport(s)andbondinggroup(s)availableonthe

NetVanta800.Intypicalconfigurations,thespecifiedoptionisanEthernetport.

2. FromtheEVC‐MapConfigurationprompt,connectthenewmaptotheEVC

bytyping

connect evc WORD,andpressENTER.

ThisattributeisthenameoftheEVCassociatedwiththemapandmustbespecified.

3. Inaddition,thefollowingattributesforthemapcanbeset:

a. Ifdesired,type

match broadcast,match multicast,and/or match unicast.

Toremoveanattributetype

no match broadcast,no match multicast,orno

match unicast

b. CEVLANID:ThisaddsthecustomeredgeVLANIDtothematchcriteriaofthe

map.Tosetthisvalue,type

matchce-vlan-id <0-4094>.Toremovethis

attributefromthematchcriteria,type

no match ce-vlan-id.

c. CEVLANPriority:ThisaddsthecustomeredgeVLANprioritytothematch

criteriaofthemap.Tosetthisvalue,type

matchce-vlan-pri <0-7>.Toremove

thisattributefromthematchcriteria,type

no match ce-vlan-pri.Arangeof

valuescanbespecifiedaspartofthiscommand.

d. Discard:Ifthisvalueisset,theNetVantadiscardsalltrafficthatmatchesthemaps

matchcriteria.Toenablediscardingtraffic,type

connect discard.Todisable,

type

no connect discard.Thisconnectiontakestheplaceoftheconnectionto

theEVC.

NOTE

IfthemapwaspreviouslyconnectedtoanEVC,itwillhavetobereconnected

aftertheno connect discardcommandisused.

e. DifferentiatedServicesCodePoint(DSCP):ThisaddstheInternetProtocolDSCPof

thecustomertraffictothematchcriteriaofthemap.Tosetthisvalue,type

match
