Install the Access and Line Modules
RemovetheAccessModuleBlankfromtheappropriateslotoftheTotalAccess5000Chassis,
ifpresent.
Toinstallthemodule,referenceFigure2‐9.
Figure 2-9. Module Installation Steps
Latches in open
position
A
lign with
guide grooves,
slide in until
seated
Latches in
closed position
