ADTRAN Total Access 5000 Deployment Guide

Section 5, BSM Provisioning - Create an EVC Map on the Total Access 5000
65K510DEP08-1A 5-17
Themen‐pri<0‐7>commandspecifiesthep‐bitvaluetomapthetraffictointhe
upstreamdirection.
NOTE
TheEVCmapdefaultismen‐pri0.
7. FromtheEVCMapInterfaceConfigurationprompt,type
no shutdown,andpressENTER
toenabletheEVCmap.
TheEVCmapisnowcreated.
8. FromtheEVCMapInterfaceConfigurationprompt,type
end,andpressENTERtoreturn
totheEnableprompt.
9. FromtheEnableprompt,type
showevc-map WORD <shelf/slot>,andpressENTERto
viewtheEVCmapconfigurationandstatus.
UponcompletingthePPPgroup,EVC,andEVCmapprovisioning,theBSMserviceprovi‐
sioningiscomplete.IPtrafficfromthecustomer,arrivingencapsulatedinPPPframes,willbe
extractedfromthePPPtraffic,andre‐encapsulatedintoEthernetframeswithVLANand
p‐bit
valuesdictatedbytheEVC andEVCmapsettings.Ethernettrafficfromthenetworkwillhave
itsIPcontentsextractedandre‐encapuslatedintoPPPframesforpassagedownthePPP
grouptothecustomerrouter.
EVC Map Example
ThefollowingexamplecreatestheEVCmaptest_map.
TA5000#configure terminal
TA5000(config)# evc-map test_map 1/21
TA5000(config-evc test_map)# connect evc test_evc_100
TA5000(config-evc test_map)# connect uni ppp-group 1/3/5
TA5000(config-evc test_map)# match dscp 41
TA5000(config-evc test_map)# men-pri 5
TA5000(config-evc test_map)# no shutdown
TA5000(config-evc test_map)# end
TA5000# show evc test_map 1/21
Name State Status
----------------------------------------------------------------------------
test_map 1/21 Enabled Running
Match Criteria Destination
--------------------------------------------------------------------------
UNI: ppp-group 1/3/5 EVC: A_803_evc1 (501)
DSCP: 41 MEN-Pri: 5
TA5000#

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
