Total Access 5000 Business Services Deployment Guide
L-10 65K510DEP08-1A
Provision the IGMP Multicast VLAN
NOTE
Ifenabled,theRPRLineModuleontheHubNodemustenabletheMulticast
VLAN.
TheMulticastVLAN,disabledbydefault,isconfiguredontheCOTNodeRPRLineModule.
WhenanIGMPVLANisenabledandconfiguredontheGigESM,theMulticastVLANmust
beenabledontheRPRLineModule.TheIGMPVLANmust beenabledandconfiguredonthe
GigESM
oftheCOTaswellastheRTNodes.IfdisabledontheRPRLineModule,the
MulticastdownstreamtrafficwillnotworkastheRPRLineModulebydefaultdoesnotflood
thetraffic.
ToprovisionIGMPMulticastVLAN,completethefollowing:
1. FromtheRPRLineModulemenu,select
Provisioning,andpressENTER.
2. FromtheProvisioningmenu,select
Multicast VLAN,andpressENTER.
3. FromtheMulticastVLAN, selecttherequiredsetting,andpress
ENTER.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
