ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
I-12 65K510DEP08-1A
Table I-18. System Management EVC Defaults
Provisioning Option Default Setting
s‐tag 3002
men‐pri 7
ipaddress 10.100.11.138
subnetmask 255.255.255.0
Table I-19. Redundancy Defaults
Provisioning Option Default Setting
wait‐to‐restore Disabled
revertive Disabled
alarmenableprotection‐unavailable Enabled
alarmenableswitch‐to‐protect Enabled
alarmenablecard‐active Enabled
alarm‐enablepeer‐version Enabled
alarm‐enabledatabase‐sync Enabled
alarmenablepeer‐mirror Enabled
Table I-20. QOS COS-Map Defaults
Provisioning Option Default Setting
qoscos‐map0 01
qoscos‐map1 23
qoscos‐map2 45
qoscos‐map3 67
Table I-21. Queue EFM Group Defaults
Provisioning Option Default Setting
max‐depth 31
cos QueueNumber

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
