ADTRAN Total Access 5000 Deployment Guide

Section 6, EoTDM Provisioning - Disable Unused NetVanta 800 Interfaces
65K510DEP08-1A 6-29
Disable Ethernet Interfaces
ForeachEthernetportthatisnotinuseforcustomerservices,completethefollowing:
NOTE
ThismustbedonetocleartheEthernetlinkdownalarms.
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,accesstheunusedEthernetPortConfiguration
promptbytyping
interface ethernet 1/0/<port>,andpressENTER.
3. DisabletheEthernetportdownbytyping
shutdown,andpressENTER.
TheEthernetlinkdownalarmshouldnowbeclearedforthisportinthealarmlog,and
theportʹsLEDshouldbeoff.
4. Repeatsteps2and3fortheremainingunusedEthernetports.
OnceallunusedEthernetportshavebeendisabled,allEthernetalarmsshouldbecleared
inthe
alarmlog.
Disable the Gigabit-Ethernet Interface
TodisabletheGigabit‐Ethernetport,completethefollowing:
NOTE
Aportmustbeplacedoutofservice,regardlessofSFP pr esence ,toremove
thealarms.
IftheportisenabledandnoSFPispresent,therewillbeanalarmfornoSFP
beingpresent.
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,accesstheGigabit‐EthernetPortConfiguration
promptbytyping
interface gigabit-ethernet 1/0/1,andpressENTER.
3. DisabletheGigabit‐Ethernetportbytyping
shutdown,andpressENTER.
TheGigabit‐Ethernetlinkdownalarmshould nowbe clearedinthealarmlog,andtheportʹs
LEDshouldbeoff.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
