ADTRAN Total Access 5000 Deployment Guide

Section 4, EoCu Provisioning - Provisioning Summary
65K510DEP08-1A 4-3
Provisioning Summary
TocreateadatapathfromtheGigESMportontheTotalAccess5000toanEthernetporton
theNetVanta838,completethefollowingprocedure:
1. Provisionthe32‐PortSHDSLEFMAccessModule.
Formoreinformation,referto“Provisionthe32‐PortSHDSLEFM”onpage 4‐4.
2. ProvisiontheEFM
BondingProtectionModule.
Formoreinformation,referto“ProvisiontheEFMBondingProtectionModule
AdministrationState”onpage 4‐6.
NOTE
EFMBondingProtectionisoptional.
3. CreateanEFMbondinggroupattheGigESMthatbondsasetofSHDSLportsofthe
moduletogether.
ThebondinggroupactsasthedataflowaccesspointtotheNetVanta838andisthepath
downwhichthemanagementconfigurationispushed.
Formore
information,referto“CreateanEFMBondingGroup”onpage 4‐7.
4. CreateanEthernetVirtualCircuit(EVC)attheTotalAccess5000thatconnectstheEFM
grouptotheGigabitEthernetportoftheGigESM.
ThiscreatesthemappingoftheS‐taggeddata.Thisaccomplishesthefollowing:
•TheGigE
SMknowswheretosendthetaggedtrafficcominginfromthegigabit
networkport
•TheGigESMpushestheavailabletagstoeachEFMbondinggroupandtoeach
NetVanta838forthelocalNetVanta838provisioning
Formoreinformation,referto“CreateanEVCCrossConnect”onpage 4‐14.
5. Enable
EFMBondingProtection.
NOTE
EFMBondingProtectionisoptional.
Formoreinformation,referto“EnableEFMBondingProtection”onpage 4‐17.
6. LogontotheNetVanta838.
Formoreinformation,referto“LogOntotheNetVanta838”onpage 4‐20.
7. CreatetheEVCattheNetVanta838.
TheEVCisalogicalconnectionpointintothe
EFMgroup.
NOTE
•MultipleEVCscanbecreatedforagivenEFMgroup.
•FortheNetVant a,theshelfisalways1andtheslotisalwayszero.
Formoreinformation,referto“CreateanEVC”onpage 4‐21.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
