ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
5-8 65K510DEP08-1A
Provisioning Steps
ThisprocedurecreatesaPPPgroupattheCHDS3PPP/MLPPP3‐PortorDS1PPP/MLPPP32‐
PortLineModulethatbondstheDS1channelspassingwithinthephysicallayerportsofthe
accessmoduletogetherintoaPPPgroup.TheDS1PPP/MLPPP32‐PortLineModulesuses
unchannelizedDS1s.
To
createanewPPPgroup,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfiguratonprompt.
2. FromtheGlobalConfigurationprompt,type
interface ppp-group <shelf/slot/
group>
,andpressENTERtocreatethePPPgroupandaccessthePPPGroup
Configurationprompt.
Table5‐4displaysthelistofvariablesforconnectingthePPPgroup.
3. FromthePPPGroupConfigurationprompt,type 
alias WORD,andpressENTERtospecify
atextstringaliasthatcanbeusedtoreferencethePPPgroup,whereWORDisthename
ofthealias.
NOTE
Ifcreatinganamewithspaces,quotesmustbeused.For example,alias
“PPP Group A”.
4. FromthePPPGroupprompt,typeoneofthefollowingcommands:
•ToprovisiontheCHDS3PPP/MLPPP3‐PortLineModule,type
link <slot/
port:channel>
, andpressENTERtoaddaDS1channeltothePPPgroup
•ToprovisiontheDS1PPP/MLPPP32‐PortLineModule,type
link <slot/port>,
andpressEntertoaddaDS1tothePPPgroup
RepeatthissteptoaddadditionalDS1channelstothePPPgroup.
Table5‐5displaysthelistofvariablesforthePPPlink.
*‐ChannelisonlyusedfortheCHDS3PPP/MLPPP3‐PortLineModule
Table 5-4. PPP Group Connecting Variables
Syntax Description
shelf Entertheshelfnumber.Ifprovisioningasingle‐nodeconfiguration,enter1.
slot EntertheslotnumberoftheDS3module.
group EntertheuniquegroupnumberofthenewPPPgroup.
Table 5-5. PPP Link Variables
Syntax Description
slot Entertheslotnumberoftheselectedmodule.
port Entertheportnumberoftheselectedinterface.
channel
*
EntertheDS1channelnumberwithinthespecifiedDS3interface.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
