ADTRAN Total Access 5000 Deployment Guide

Section 3, Common Provisioning - Provision the GigE SM
65K510DEP08-1A 3-7
3. Typeend,andpressEntertoreturntotheEnableprompt.
Provision the Network Ports
Toconfigurethenetworkportadministrationstates,completethefollowingprocedure:
NOTE
Thisisasinglenodesetup,thereforeNetworkPort2willbesettotheOutof
Service‐Unassignedstate.Thispreventsanyunnecessaryalarmsforthe
unusednetworkport.
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface gigabit-ethernet 1/A/1,
andpress
ENTERtoaccessthe slotA,Net1Configurationprompt.
3. Type
no shutdown,andpressENTERtosettheporttoInService.
4. Type
interface gigabit-ethernet 1/A/2,andpressENTERtoaccesstheslotANet2
Configurationprompt.
5. Type
shutdown,andpressENTERtosettheporttoOutofService,Unassigned.
6. Type
exit,andpressENTERtoreturntotheGlobalConfigurationprompt.
7. Type
interface gigabit-ethernet 1/B/1,andpressENTERtoaccesstheslotB,Net1
Configurationprompt.
8. Type
no shutdown,andpressENTERtosettheporttoInService.
9. Type
interface gigabit-ethernet 1/B/2,andpressENTERtoaccesstheslotB,Net2
Configurationprompt.
10. Type
shutdown,andpressENTERtosettheporttoOutofService,Unassigned.
11. Type
end,andpressENTERtoreturntotheEnableprompt.
NOTE
TheGigESMNET 1LEDshouldbegreen.Ifnot,performphysic allayer
diagnostics.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
