ADTRAN Total Access 5000 Deployment Guide

Appendix J, GigE Star Provisioning - Central Office Terminal (COT) Provisioning
65K510DEP08-1A J-7
Table J-4. T1 8-Port Line Module Provisioning Defaults
Option Settings Default
Provisioning
CardServiceState InService;
OutofService‐Unassigned;
OutofService‐Maintenance
OOS‐Maintenance
CardMode
EFM/PWE3 EFM(NetworkMode);
PWE3(Pseudowire)
EFM(Network
Mode)
DS1Interfaces
ServiceState InService;
OutofService‐Unassigned;
OutofService‐Maintenance
OOS‐Unassigned
OutputLBO 0‐133ft;
133‐266ft;
266‐399ft;
399‐533ft;
533‐655ft;
9dB;
0dB;
–7.5dB;
–15dB;
–22.5dB
0‐133ft
LineCode B8Zs;
AMI
B8ZS
LineType ESF;
D4;
Unframed
Unframed
SpanVoltage Disabled;
–130VDC;
(260VDC)±130VDC;
Loopback
Disabled
EFMSettings
UplinkIdentifier System;
SelectEFMGroup
System
Timing
LoopATiming None;
DS1‐1
None
LoopBTiming None;
DS1‐1
None

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
