ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
Intro-2 65K510DEP08-1A
Related Documentation
RefertoTableIntro‐2foradditional,detailedsysteminformationconcerningtheBusiness
Servicesdeployment.Fordetailedcomponentinformation,refertotheapplicableInstallation
andMaintenanceGuidesandJobAidsfortheindividualcomponentproduct.
AppendixJGigEStarProvisioning
AppendixKGigELinearChainProvisioning
AppendixLRPRProvisioning
AppendixMAdd/RemoveNodefromRPRRing
AppendixNERPSProvisioning
AppendixO LoopbackProvisioning
Table Intro-2. Related System Documentation
Title Part Number
TotalAccess/NetVantaCarrierCLIDictionary 6TANV510CLI‐35
TotalAccess5000/5006EngineeringandOrderingGuideSystemRelease5.1 65K510ENG‐1
TotalAccess5000I/OModuleConfigurationJobAid 65K510XMIO‐22
TotalAccess5000/5006LoadCalculationGuidelinesJobAid 65KLOADCALC‐22
BroadbandSFP/XFPMatrixApplicationNote 61442000G1‐49
Table Intro-1. Topic List
Section Topic

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
