ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
J-14 65K510DEP08-1A
7. FromtheGlobalConfigurationprompt,provisionthemoduleadministrationstateby
performingoneofthefollowingcommands:
•Type
no slot shutdown <shelf/slot>,andpressENTERtotakeaslotInService
•Typeslot
shutdown maintenance <shelf/slot>,andpressENTERtotakeaslot
OutofService,Maintenance
•Type
slot shutdown <shelf/slot>,andpressENTERtotakeaslotOutofService,
Unassigned
8. FromtheGlobalConfigurationprompt,type
interface t3 <shelf/slot/port>,and
press
ENTER.
9. Provisiontheportadministrationstatebyperformingoneofthefollowingcommands:
•Type
no shutdown,andpressENTERtotakeaportInService
•Type
shutdown maintenance,andpressENTERtotakeaportOutofService,Mainte‐
nance
•Type
shutdown,andpressENTERtotakeaportOutofService,Unassigned
Provision the Uplink Identifier
Toprovisiontheuplink identifier,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
ethernet default interface efm-
group WORD
,andpressENTER.
NOTE
UsetheWORDinputtoenterastringwithoutspaces.Thisinputiscase
sensitive.
WORDisthegroupnameassignedwhenconfiguringtheEFMgroupusingEZ‐EFM.
Provision the Timing Source
Toprovisionthetimi ngsource,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
system-timing <shelf>,andpress
ENTER.
3. FromtheSystem‐TimingConfigurationprompt,type
source primary loop-a
interface t3 <shelf/slot/port>
,andpressENTER.
4. FromtheSystem‐TimingConfigurationprompt,typesource secondary loop-b
interface t3 <shelf/slot/port>
,andpressENTER.
NOTE
ADTRANrecommendshavingtheprimaryandsecondarytimingsourcesbe
ondifferentDS3portsandadjacentredundantslots.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
