ADTRAN Total Access 5000 Deployment Guide

Appendix F, NetVanta Examples - EVCs
65K510DEP08-1A F-5
Admin State
Thisattributeistheuser‐configurablestateoftheEVC.TableF‐4liststhe availableoptions.
MEN Port
ThisattributeisthephysicalinterfaceconnectedtotheMEN.Thepossibleoptionsconsistof
theEthernetport(s)andbondinggroup(s)availableonthespecificproduct.Intypicalconfig‐
urations,theMENportisspecifiedasabondinggroup.OneormoreMENportscanbe
directlyconnectedtoanEVC.
AconnectedMENporthasanassociatedstatusthatdetermines
ifitcanbeusedbytheEVCtotransmit/receivetraffic.Thisstatusisread‐onlytoanEVCand
iscontrolledbyexternalprocesses(forexample,LinkOAMorEVCAdvertisement).Ports
disallowedbyexternalprocessescannotbeusedduring
thevalidationoftheconfigurationof
anEVC.
S-tag
ThisattributeistheVLANIDassociatedwiththeEVCs‐tag.TheEVCVIDissetusingthes‐
tagcommand.Ifthealiasspecifiedduringcreationisnumeric,thes‐tagwilldefaulttomatch.
List of Connected EVC Maps
ThisattributelistsallEVCmapsconnectedtotheEVC,eachwithanassociatedstatus.EVC
mapslistedas“Running”cantransmit/receiveEVCtraffic.
NOTE
NotallEVCmapsarerequiredtobeinthe“Running”statefortheEVCtobe
successfullytransportingtraffic.
CE-VLAN Preservation
ThisattributecontrolswhethertopreservetheCE‐VLANtagwithintheEVC.Thisoption
mustbeenabledifmultipleCE‐VLANsareforwardedtotheEVC(RefertoRule9onpage F‐
2).TableF‐5liststheavailableoptions.
Table F-4. EVC State Options
Option Definition
Enabled TheEVCisinservice,andtheprovisioningisappliedifthecon‐
ditionsarevalid.
Disabled TheEVCisnotinservice,andtheprovisioningisnotapplied.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
