ADTRAN Total Access 5000 Deployment Guide

65K510DEP08-1A F-1
Appendix F
NetVanta Examples
Scope of this Appendix
ThisappendixdetailsavarietyofdifferentusesfortheNetVantaproducts.
In this Appendix
Thisappendixcontainsthefollowingtopics:
Table F-1. Appendix F Topics
Topic See Page
RulesforProvisioningEVCs,EVCMaps,andPolicers F‐2
EVCs F‐4
EVCMaps F‐7
BandwidthPolicer F‐14
NetVanta800/8000SeriesApplications F‐19

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
