ADTRAN Total Access 5000 Deployment Guide

Section 2, Installation - Install the SMIO3
65K510DEP08-1A 2-3
Install the SMIO3
Thissubsectiondetailsthefollowing information:
•SMIO3Description
• InstallationSteps
SMIO3 Description
TheSwitchModuleInput/Output3(SMIO3)supportsoneSystemControllerModule(SCM)
andtwoSwitchModules(SM).
TheSMIO3providesthefollowing:
•Physicalinterface(3slots)totheTotalAccess5000backplanefortheSCMandtwoSMs
•PhysicalcommunicationpathsbetweentheSCMandtheSMs
• CommunicationinterfaceportstotheSCM
thatenablemanagementoftheTotalAccess
5000system
•Wire‐wrapterminalsforexternalclocks,alarmI/O,testing,andvoltage
• ControlsignalsandapowerpathtotheFanModule
Installation Steps
TheSMIO3attachestothebackoftheTotalAccess5000chassis.ToinstalltheSMIO3,
completethefollowing:
CAUTION
!
Ifthechassisisrackmounted,besurethatthechassisissquareandnot
distortedbytherackframebeforeinstallingtheSMIO3.Toaidins tallation,
loosenthechassismountingboltstoallowthechassistobecomesquare.
NOTE
Beforeinstallingthe chassis,installtheSMIO3.InstallingtheSMIO3ensures
therelayrack,ifnotsquare,will notwarpthechassis .Ifnotdoneproperly,
theSMIO3mountingscrew swillnotmatewi ththechassis. Forinstallation
instructions,refertotheTotalAccess5000SwitchModuleI/O3(SMIO3)JobAid
(P/N61187051L1‐22).
1. AligntheSMIO3acrossslotslabeled
12/SCM,SM A,andSM B(labeledinthefrontofthe
chassis).SeattheSMIO3ontotheinstallationpegsofthechassissothatitrestsfirmly
againstthechassisframe.
2. Attachthemoduletothechassisusingthefourphillipsscrewsandthreestand‐offs
provided(seeFigure2‐1).
3. Usinga#1phillips‐head
screwdriver,attachtheguardtothechassisusingthetwo
screwstosecuretheguard.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
