ADTRAN Total Access 5000 Deployment Guide

65K510DEP08-1A Intro-1
Introduction
Scope of this Guide
ThisguideprovidestheminimumconfigurationstepsneededfortheEthernetoverCopper
(EoCu),BusinessServiceMigration(BSM),EthernetoverTDM(EoTDM),andEthernetover
Fiber(EoF)deployments.
In this Guide
ThisguidecontainsthetopicslistedinTableIntro‐1.
Table Intro-1. Topic List
Section Topic
Section1BusinessServicesOverview
Section2 Installation
Section3CommonProvisioning
Section4EoCuProvisioning
Section5BSMProvisioning
Section6EoTDMProvisioning
Section7EoFProvisioning
AppendixALinkAggregationGuide
AppendixBSHDSLRateReachInformation
AppendixCEthernetOAMProvisioning
AppendixDTWAMPProvisioning
AppendixEDynamicCountersProvisioning
AppendixFNetVantaExamples
AppendixGBSMDS3/DS1Layer1Tests
AppendixHAlarmSeverities
AppendixI5.1ProvisioningDefaults

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
