ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
7-6 65K510DEP08-1A
Create an EVC Cross Connect
Thissubsectiondetailsthefollowing information:
• DefinitionofanEVC
•GuidelinesforcreatinganEVC
•StepsforcreatinganEVC
EVC Definition
AnEVCisalogicalenti tythatprovidesameansforconnectingtwoendpointsintheTotal
Access5000andprovidesapathforEthernetframeswithaparticularVLANIDwithinthe
TotalAccess5000. TheEVCcross‐connectstwoormoreendpointsandprovidesthe
mechanismbywhichan
S‐tagpathiscreatedinthesystem.TheS‐tagcorrespondstothe
VLANID.
IntheTotalAccess5000,customertrafficswitchesthroughoutthesystemviaS‐tags
(outermostVLANtagonanEthernetpacket).Downstreamtrafficentersthesystemthrough
thenetworkportsontheGigESMand
isS‐tagswitchedtotheappropriateslot.TheGE8‐Port
LMthendecideshowtosendthattraffictothecustomer.Upstreamtrafficisswitchedtothe
networkinasimilarmanner.
NOTE
If the NetVanta 8044 management VLAN differs from the GigE SM
managementVLAN,createanEVCfortheGigESMtopasstheNetVanta
8044managementtraffic.Whencre atingacrossconnect,setupthecross
connectwithanS‐tagequaltothe NetVanta8044managementVLAN,
pointingtotheappropriateappropriateGigE8‐PortLMport.
EVC Cross Connect Guidelines
Whencreatingacross‐connect,enforcethefollowingguidelines:
•AnEVCcannotbepartofanothercross‐connect
• EachEVCmusthaveauniqueS‐tag
Table7‐3displaystheavailableS‐tagsintheTotalAccess5000.
Table 7-3. Available S-tag Range
S-tag Function
0,1,4095 Reserved
2–4094 EVPLsandInbandManagementVLAN
3072 InternalManagementVLAN(Default)

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
