ADTRAN Total Access 5000 Deployment Guide

Appendix M, Add/Remove Node from RPR Ring - Perform a Manual or Forced Switch
65K510DEP08-1A M-3
Figure M-2. Current Protection Menu
4. FromtheCurrentProtectionmenu,press
EorWtochangethedirectiontoEastorWest.
5. FromtheCurrentProtectionmenu,selecttheappropriateswi tch,andpress
ENTER.
Thefollowingoptionsareavailable:
•ForceSwitch:Thisselectionforcestrafficawayfromthespan,regardlessofthering
state
•ManualSwitch:Thisselectionforcestrafficawayfromthespan,onlywhenthering
isclosed,withnoerrors
TID: TA5000 Total Access 5000 System MM/DD/YY hh:mm
Unacknowledged Alarms: None Node: 1
Current West Protection: Idle
1. Force Switch
2. Manual Switch
3. Idle
Selection : 2
W-West E-East
'?' - System Help Screen

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
