ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
L-6 65K510DEP08-1A
Figure L-4. RPR Line Module Provisioning Menu
2. FromtheProvisioningmenu,selectCard Service State,andpressENTER.
3. FromtheCardServiceStatemenu,selecttheappropriateservicestate,andpress
ENTER.
Provision the Hub/Spoke
RingsoriginatingataCOTNoderequirenoprovisioning.
NOTE
•IfanRPRring originatesataRemoteTerminal,thentheHub/SpokeMode
mustbesettoHubontheoriginatingNode.
•TheCOTNodeautomaticallysetstoHubMode.
ToprovisiontheHub/Spoke,completethefollowing:
1. FromtheRPRLineModulemenu,select
Provisioning,andpressENTER.
2. FromtheProvisioningmenu,select
Hub/Spoke Mode,andpressENTER.
3. FromtheHub/Spokemenu,selecttherequiredoption,andpress
ENTER.
TID: HSV00001 Total Access 5000 System MM/DD/YY HH:MM
Unacknowledged Alarms: None Unit Number: 1
RPR LM Provisioning
1. Card Service State : In Service
2. Redundancy
3. RPR Provisioning
4. Allow Any SFP : no
5. Timing : Loop A / Loop B
6. Software Update
7. Restore Factory Defaults
8. Multicast VLAN : Disabled
9. Hub/Spoke Mode : Hub/Spoke
Selection :
'?' - System Help Screen

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
