ADTRAN Total Access 5000 Deployment Guide

Section 1, Business Services Overview - Business Services Migration Overview
65K510DEP08-1A 1-7
Business Services Migration Components List
Table1‐3liststheproductsneededfortheBusinessServiceMigrationdeployment.
CAUTION
!
Duetocompliance certificationrequirements, only SFPs supplied by
ADTRANaretobeusedwiththeTotalAccess5000modules.ADTRAN
cannotcertifysystemintegritywhennonADTRANsuppliedSFPsareused.
Table 1-3. Deployment Part Numbers
Part Number Description CLEI
TotalAccess5000Components
1187001L1 23‐InchChassis BVM2V10G__
1187010L1 SystemControllerModule(SCM) BVCUD0YM__
1187010G2 SCM,SecondGeneration BVC1AA6E__
1187011G1 BridgingSCM BVC1ABGE__
1187020G1 SwitchModule2Gigabit,noRingGenerator BVL2N0NC__
1187020G2 SwitchModule2Gigabit,w/RingGenerator BVL2N0PC__
1187025G1 SwitchModule2‐10G/2‐1Gigabit,noRingGenerator BVL3AE4D__
1187025G2 SwitchModule2‐10G/2‐1Gigabit,w/RingGenerator BVL3AE5D__
1187030G1 Switch
Module5,2‐10G/2‐1/2.5Gigabit,noRingGenerator BVL3AE6D__
1187051L1/G1 SwitchModuleI/O3(SMIO3) BVL2PT0C__
1187220G1 CHDS3PPP/MLPPP3‐PortLineModule BVL3AFND__
1187400G1 LineModuleInput/OutputDualChamp64‐PinBridgedRear
Panel
BVL260DC__
1187402G1 LineModuleInput/OutputDualHDDS1DividedPairRear
Panel
BVL3ADRD__
1187442E1 LineModuleInput/Output(LMIO2)DS3
8NR(Non‐Redun‐
dant)
BVM6C00A__
1187443L1 LineModuleInput/Output(LMIO2)DS3BNC4R(Redundant) BVM6D00A__
1187803G2 DS1PPP/MLPPP32‐PortLineModule BVL3AHRD__
1187080L1 23‐InchFanModule BVPQADGM__
1187081L1 23‐InchFanFilter N/A

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
