ADTRAN Total Access 5000 - Figure 1-5. Eotdm DS3 3-Port General Application Diagram

Section 1, Business Services Overview - Ethernet over TDM Overview
65K510DEP08-1A 1-9
Figure 1-5. EoTDM DS3 3-Port General Application Diagram
SONET
Multiplexer
(Central Office)
Total Access 5000
Central Office
Router
NetVanta 818
DS1s
DS3s
NetVanta 818
Router
Customer Site
Customer Site
Router
Customer Site
DS1s
NetVanta 818
EoTDM
Channelized Application
