ADTRAN Total Access 5000 Deployment Guide

Section 3, Common Provisioning - Provision the GigE SM
65K510DEP08-1A 3-9
Oncethenodenumberisprovisioned,thenetworkportsareconfiguredasfollows:
•Ifthenodeissetto1,thenNet1isinNetworkInterfacemode,andNet2isunused
•Ifthenodeisgreaterthan1,thenNet1isinUplinkmode,andNet2isunused

TodesignateNet2asthedefaultinterface,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
ethernetdefaultinterface
gigabit-ethernet 1/A/2
.andpressENTER.
NOTE
•IfNet2isdesignatedasthedefaultEthernetinterface,thenNet1becomes
unused.
•Ifitistobeused,LACPstillneedstobeenabledontheactiveports.
Port Mode Configuration Examples
Thissectiondisplaysalistofportmodeconfigurationexamples.
Example #1
ThestepstoturnupasystemwithNet1astheNetworkInterfaceandNet2asUnused(from
thedefaults)are:
#configure terminal
(config)#node number 1
(config)#exit
#
Example #2
ThestepstoturnupasystemwithNet1astheNetworkInterfaceandNet2asaDownlink
are:
#configure terminal
(config)#node number 1
(config)#interface gigabit-ethernet 1/A/2

(config gig-eth 1/A/2)#downlink
(config gig-eth 1/A/2)#
exit
(config)#exit
#
Example #3
ThestepstoturnupasystemwithNet1asUplinkandNet2asUnusedare:
#
configure terminal
(config)#node number 2
(config)#
exit
#

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
