ADTRAN Total Access 5000 Deployment Guide

65K510DEP08-1A L-1
Appendix L
RPR Provisioning
Scope of this Appendix
Thisappendixdetailsthestepstoprovisionthe TotalAccess5000networkinaResilient
PacketRing(RPR)configuration.
In this Appendix
Thisappendixcontainsthefollowingtopics:
Basic RPR Rules
WhenprovisioningRPR,thefollowingrulesmustapply:
•RPRRingscanoriginatefromtheCOTNodeoraRTNode.Ifthe RingoriginatesatanRT
node,thenthatRPRcardmustbeconfiguredasaHub
•RingSpeedis2.5GwithAdd/Dropof1Gperspan
•ThesameVLANcannot
beconfiguredonMultiplenodeswithinaRing.Ifdone,the
ActiveRPRLineModuleraisesaVLAN MisConfigalarmontheCOTNode
•EnsuretheS‐tag TPIDintheSwitchModuleissetto0x8100
•RPRissupportedwithapairofcardsinadjacentsl ots(odd/evenpairs).Each
card
providesoneoftheNode’slinksonthering
Table L-1. Appendix L Topics
Topic See Page
BasicRPRRules L‐1
EthernetRingDiagrams L‐2
CentralOfficeTerminal(COT)NodeProvisioning L‐3
RemoteTerminal(RT)Provisioning L‐8

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
