ADTRAN Total Access 5000 Deployment Guide

Appendix L, RPR Provisioning - Remote Terminal (RT) Provisioning
65K510DEP08-1A L-9
Provision the RPR Line Module
OncetheRTGigESMisprovisioned,thefollowingfeaturesoftheRPRLineModulemustbe
set:
•ProvisiontheTiming
•ProvisiontheHub/Spoke
•ProvisionIGMPMulticastVLAN
Provision the Timing
TheactiveRPRLineModulemustbeprovisionedwithLoopAbeingWestandLoopBbeing
East.ToprovisiontheRPRtiming,completethefollowing:
1. FromtheRPRLineModulemenu,select
Provisioning,andpressENTER.
2. FromtheProvisioningmenu,select
Timing,andpressENTER.
3. FromtheTimingConfigurationmenu,press
E.
4. FromtheTimingConfigurationmenu,selectSetTimingtoLoopB,andpress
ENTER.
5. FromtheTimingConfigurationmenu,press
W.
6. FromtheTimingConfigurationmenu,selectSetTimingtoLoopA,andpress
ENTER.
Provision the Hub/Spoke
RingsoriginatingataCOTNoderequirenoprovisioning.
NOTE
•IfanRPRring originatesataRemoteTerminal,thentheHub/SpokeMode
mustbesettoHubontheoriginatingNode.
•TheCOTNodeautomaticallysetstoHubMode.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
