Total Access 5000 Business Services Deployment Guide
2-14 65K510DEP08-1A
Figure 2-7. Installing the Transmit and Receive DS3 Cables
DS3 2NR
BNC
1187441L1
TX1 RX1
TX2 RX2
TX3 RX3
TX4 RX4
TX1 RX1
TX2 RX2
TX3 RX3
TX4 RX4
E
V
E
N
S
L
O
T
O
D
D
S
L
O
T
DS3 8NR
1187442E1
Transmit
Receive
Transmit
Receive
Transmit
Receive
1187440L1
Redundant BNC Rear Panel
1187441L1
Non-Redundant BNC Rear Panel

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
