ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
A-4 65K510DEP08-1A
3. FromtheGigabitEthernetInterfaceConfigurationprompt,typelacp mode activeor
lacp mode passive,andpressENTERtoconfiguretheinterfaceforthedesiredLACP
mode.
4. Repeatsteps2to3toenableLACPforallactivegigabit‐ethernetinterfacesinthelink
aggregationgroup.
5. FromtheGigabitEthernetInterfaceConfigurationprompt,type
end,andpressENTERto
returntotheEnableprompt.
Configure Default Network Interface
Toconfigurethedefaultnetworkinterface,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
ethernet defaultinterface lag-
group 1/A/1
,andpressENTERtosetthedefaultnetworkinterfacetothenewlycreated
linkaggregationgroup.
3. FromtheGlobalConfigurationprompt,type
endandpressENTERtoreturntotheEnable
prompt.
Configure EVCs
Oncealinkaggregationgroupiscreated,itcanbeincludedintheTotalAccess5000cross
connects.TocreateanEVCandconnectittoalinkaggregationgroup,complete thefollowing
procedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtogettotheGlo‐
balConfigurationprompt.
2. FromtheGlobal Configurationprompt,type
evc WORD,andpressENTERtocreateanEVC
withnameevc_name.
3. FromtheEVCI n terface Configurationprompt,type
s-tag <1-4094>,andpressENTER
tosettheS‐tagofthe EVC.
4. FromtheEVCI n terface Configurationprompt,type
connect men-port lag-group
<1/slot/port>
,andpressENTERtoconnectthedesiredlinkaggregationgrouptothe
EVC.
NOTE
Thiscommandentryap pliestotheactiveGigESM,independentofwhich
GigESMisactuallyspecified,inanActive/Standbyconfiguration.
5. FromtheEVCI n terface Configurationprompt,type
connect men-port efm-group
<shelf/slot/group>
,andpressENTERtoconnecttheEFMbondinggrouptotheEVC.
NOTE
TheEFMbond ing groupshe lf/slot/groupdesignationcanbeusedinlieuof
thegroupname.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
