ADTRAN Total Access 5000 Deployment Guide

Section 2, Installation - Install the Front Panel Modules
65K510DEP08-1A 2-19
EFM Bonding Protection Module Description
TheEFMProtectAccessModuleprovidesEFMbondingengineprotectionforanyEFM
SHDSLorDS1EFM(1187802L1)accessmoduleinstalledinaTotalAccess5000system
beginningwithSystemRelease3.2.ThesemodulesmustsupportEFMbondingandhavebeen
cross‐slotprovisioned.
Install the EFM Bonding Protection Module
NOTE
ADTRANrecommendsinstallingtheEFMProtectAccessModulein slot11
or21oftheTotalAccess5000chassis.
ToinstalltheEFMProtectAccessModule,completethefollowingsteps:
1. PulltheejectorlatchesontheEFMProtectAccessModule,locatedontheupperand
lowerleft‐handsideoftheEFMBondingProtectionModulefrontpanel,fromtheclosed
positions.
2. Holdthe
EFMProtectAccessModulebythefrontpanelwhilesupportingthebottom
edgeofthemodulewiththeejectorlatchesopenedtoengagethechassis.
3. AligntheEFMProtectAccessModuleedgestofitinthelowerandupperguidegrooves
ofthemoduleslot.
4. SlidetheEFMProtectAccessModule
intothemoduleslot.Applysimultaneousthumb
pressureatthetopandbottomofthemodule(totherightoftheejectorlatches)toensure
thatthemoduleisfirmlyseatedagainstthebackplane.
5. SecuretheEFMProtectAccessModuleinplacebyrotatingtheejectorlatchesintothe
lockedpositions.
6. Install
oneofthefollowingAMIO1BlankPanelsontherearoftheTotalAccess5000
ChassisdirectlybehindtheEFMProtectAccessModule:
•P/N1187925L1isusedwiththeTotalAccess5000non‐shield ed chassis(1187001L1)
•P/N1187925G1isusedwiththeTotalAccess5000shieldedchassis(1187001G1)
Afterinstallationiscomplete,
theEFMProtectAccessModuleperformsaseriesofinitial‐
izationandself‐tests.Oncetheseriesofself‐testsarecompleted,thefrontpanelLEDsreflect
thetruestateofthehardware.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
