ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
F-14 65K510DEP08-1A
Bandwidth Policer
Abandwidthpolicerisamethodofcharacterizingserviceframesforthepurposeofrate
enforcement.Abandwidthpolicercanbeappliedinoneofthefollowingways:
•IngressbandwidthpolicerperingressUNI
•IngressbandwidthpolicerperEVC
•Ingressbandwidthpolicerpercustom
Intypicalapplications,thebandwidthavailableontheEVC
islessthanthebandwidth
availableattheUNIport.Thebandwidthbottleneckistypicallyonlyinthe UNI‐to‐MEN
direction;therefore,allbandwidthpolicersareappliedonlyfortrafficconductedintheUNI‐
to‐MENdirection.PolicersarenotappliedtothetrafficconductedintheMEN‐to‐
UNI
direction.
Bandwidth Policer Attributes
Theattributesofabandwidthpoliceraredescribedinthefollowingparagraphs.
Name
Thisattributeisanarbitrarystringthatisusedtoidentifythepolicer.Thevaluemustbe
uniqueacrossallpolicersdefinedintheproduct,andisintendedformanagementandcontrol
purposes.ThevalueisnotcarriedinanyfieldintheEthernetframe.
Configuration Status
Thisattributeisaread‐onlystatusidentifierofthepolicer.Thepolicercanbeadministratively
enabled,butitcannotbeinfunctionalstateifitisnotfullyconfiguredorifthereisaconflict.
TableF‐11liststhepossiblevalues.
Table F-11. Policer Status Values
Possible Value Definition
Running Thepolicerisrunningandapplyingingressabandwidthprofile
toanymatchingEVCmaps.
Disabled TheadministrativestateofthepolicerisprovisionedasDisabled.
Duplicatepolicer Anenabledpolicerwithequalprecedenceandequalvalueexists.
RefertoRule4onpage F‐2.
Invalidrate(s) ThevaluesforCIRand/orEIRconflictin
relationtotheratecou‐
plingvalue.
NoMode Themodeattributeofthepolicerisnotset.
UnknownUNI ThemodeisperUNIandtheUNIcannotbefound.
UnknownEVC ThemodeperEVCandtheEVCcannotbefound.
UnknownEVC‐map ThemodeperCustomandtheEVCmap
cannotbefound.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
