ADTRAN Total Access 5000 Deployment Guide

Section 2, Installation - Install and Connect the Rear Panel Components
65K510DEP08-1A 2-15
Install the Rear Panels
Toinstallthepush‐throughpanels,completethefollowingprocedure(seeFigure2‐8and
Table2‐2):
Figure 2-8. Installing the Rear Panels
WARNING
!
Tomeet NEBSLevel3andprovide properairflow andfiltration,the
applicablerearpanelmustbeinstalledinanyoccupiedslot,andafrontand
rearblankpanelmustbeinstalledinanyemptyslots.
Table 2-2. Rear Panel Installation Steps
Step Description
1 Positiontherearpanelonthebackofthechassissothatthemiddlenotch onthepanelaligns
withthechassisalignmentpin.Therearpanelisprovidedwithasetofcaptivescrews.
Thesescrewsinsertintothechassis’screwmountingholes.UseaPhillipsscrewdriverto
tightenthecaptivescrews,securingthepaneltothechassis.
2InstalltheChampMountingBrackettothebottomofthe90°malechampconnectorusing
one#4‐40x0.35inchCaptiveScrew.Therearpanelisprovidedwithasetof#4‐40x0.35inch
CaptiveScrewsforinstallationof
twoconnectorstothepanel.Usetwoscrewsforeachcon‐
nector,oneforthemountingbracket,thesecondtosecuretheconnectortothepanel(see
Step3).ReplacetheCaptiveScrewprovidedwiththecableifitisnota0.35inchscrew.
3Installthe90°malechampconnector
totherearpanelbyslidingthemountingbracketdown
intothepanelslot,andsecuringwitha#4‐40x0.35inchCaptiveScrewatthetopofthe
champconnector.
2.
1.
3.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
