Section 2, Installation - Install the Front Panel Modules
65K510DEP08-1A 2-17
Install the SCM
ToinstalltheSCM,completethefollowingprocedure:
NOTE
TheSMIO3mustbeinstalledbeforeinstallingtheSCM.
1. Pulltheejectorlatches,locatedontheupperandlowerlefthandsideoftheSCMfront
panel,fromtheclosedpositions.
2. HoldtheSCMbythefrontpanelwhilesupportingthebottomedgeofthemodulewith
theejectorlatchesopenedto
engagethechassisedges.
3. Alignthemoduleedgestofitinthelowerandupperguidegroovesfortheslotlabeled
12/SCM.
4. Slidethemoduleintothemoduleslot.Applysimultaneousthumbpressureatthetop
andbottomofthemodule(totherightoftheejectorlatches)toensurethatthemoduleis
firmlyseatedagainstthebackplaneofthe chassis.
5. SecuretheSCMinplacebyrotatingtheejectorlatchesinto
thelockedpositions.
GigE SM Description
TheGigESwitchModule(SM)providesnetworkdataaggregationfortheTotalAccess5000
system.TheGigESMswitchesEthernettrafficfromtheSFPinputstotheAccessModuleslots.
TheGigESMcontrolscommonsystemfunctionsandcommunicationbetweenaccessmodules
andtheSCM.TheGigESMinterfacestothe
highspeedbackplanethroughtheSMIO3.
Install the GigE SM
ToinstalltheGigESM,completethefollowing:
NOTE
TheSMIO3mustbeinstalledpriortoinstallingtheGigESM.
1. Pulltheejectorlatches,locatedontheupperandlowerlefthandsideoftheGigESM
frontpanel,fromtheclosedpositions.
2. HoldtheGigESMbythefrontpanelwhilesupportingthebottomedgeofthemodule
withtheejectorlatchesopenedtoengagethechassisedges.
3. AlignthemoduleedgestofitinthelowerandupperguidegroovesoftheSwitch
Moduleslotlabeled
SM AorSM B.
4. SlidetheGigESMapproximatelyhalfwayintothemoduleslotandinsertthecopperor
opticalcableintotheSFPmodule.
5. ContinueslidingtheGigESMintothe chassis,applyingsimultaneouspressureatthetop
andbottomofthemodule(totherightoftheejectorlatches)toensurethatthe
moduleis
firmlyseatedagainstthebackplaneofthe chassis.
6. SecuretheGigESMinplacebyrotatingtheejectorlatchesinto thelockedpositions.
7. Connectthecopperoropticalcableswiththeappropriateconnectorthatmatchesthe
SFP.
