ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
2-18 65K510DEP08-1A
8. Routethecopperoropticalcabletothecabletraylocatedatthebottomofthemodule
slotsanddresswithappropriateties.
Install the SFPs
CAUTION
!
Duetocompliance certificationrequirements, only SFPs supplied by
ADTRANaretobeusedwiththeTotalAccess5000modules.ADTRAN
cannotcertifysystemintegritywhennonADTRANsuppliedSFPsareused.
ToinstallanSFPintoanappropriatemodule,completethefollowing:
1. InspecttheSFPfordamage.Ifdamaged,fileaclaimwiththecarrierandthencontact
ADTRANCustomerService.
2. InserttheSFPintotheSFPcageontheswitchmodule,
withthelabelfromthe
manufacturerfacingtotheright.SlidetheSFP allthewayintothecageuntilitclicksinto
place.
3. RemovethesafetycapfromtheopticalconnectorsoftheSFP.
4. InsertthefiberconnectorintotheSFPuntilitclicksintoplace.
CAUTION
!
DonotattempttoremovetheSFPwiththefiberinstalled.
32-Port SHDSL EFM Description
The32‐PortSHDSLEFMprovides32SHDSLlinksthatcanbebondedwithEthernetinthe
firstmile(EFM).EachSHDSLlinkiscapableofdataratesfrom192kbpsto5.7Mbpsin64
kbpsincrements.Forproperfunctionality,the32‐PortSHDSLEFMmustbeinstalledina
Total
Access5000shelfthathasaSMinstalled.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
