ADTRAN Total Access 5000 Deployment Guide

Section 5, BSM Provisioning - Create a Point-To-Point Protocol Group
65K510DEP08-1A 5-11
Add a Link to the PPP Group
ToaddalinktothePPPgroup,completethefollowingsteps:
1. FromtheEnableprompt,type
show interfaces ppp-group,andpressENTERtoview
allPPPgroupsintheTotalAccess5000.
NOTE
Asan alternative,type show ppp-group <shelf>or show ppp-group
<shelf/slot>
toseeanabbreviatedlistofppp‐groups/linksontheshelfor
theslot.
2. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccessthe
GlobalConfigurationprompt.
3. FromtheGlobalConfigurationprompt,type
interface ppp-group <shelf/slot/
group>
,andpressENTERtoaccessPPPGroupInterfaceConfigurationprompt.
4. Ifaddingasecondlink,MultilinkPPPmustbeenabled.FromthePPPGroupInterface
Configurationprompt,type
ppp multilink,andpressENTER.
5. FromthePPPGroupInt erfaceConfigurationprompt,typeoneofthefollowing
commands:
•ToprovisiontheCHDS3PPP/MLPPP3‐PortLineModule,type
link <slot/
port:channel>
,andpressENTERtoaddalinktothegroup
•ToprovisiontheDS1PPP/MLPPP32‐PortLineModule,type
link <slot/port>,
andpress
ENTERtoaddalinktothegroup
Delete a Link from the PPP Group
ToremovealinkfromthePPPgroup,completethefollowingsteps:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface ppp-group <shelf/slot/
group>
,andpressENTERtoaccessPPPGroupInterfaceConfigurationprompt.
3. FromthePPPGroupInt erfaceConfigurationprompt,typeoneofthefol lowing 
commands:
•ToprovisiontheCHDS3PPP/MLPPP3‐PortLineModule,type
no link <slot/
port:channel>
,andpressENTERtoremovealinktothegroup
•ToprovisiontheDS1PPP/MLPPP32‐PortLineModule,type
no link <slot/
port>
,andpressENTERtoremovealinktothegroup

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
