ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
J-12 65K510DEP08-1A
9. Provisiontheportadministrationstatebyperformingoneofthefollowingcommands:
•Type
no shutdown,andpressENTERtotakeaportInService
•Type
shutdown maintenance,andpressENTERtotakeaportOutofService,
Unassigned
•Type
shutdown,andpressENTERtotakeaportOutofService,Unassigned
Provision the Network Ports
Toconfigurethenetworkportadministrationstates,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface gigabit-ethernet
<shelf/slot/port>
,andpressENTERtoaccesstheEthernetInterfaceConfiguration
prompt.
3. Type
no shutdown,andpressENTERtosettheporttoInService.
4. Repeatsteps2and3foreachportbeingused.
Provision the Ethernet Star
ToconfiguretheTotalAccess5000foraGigabitEthernetStar,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface gigabit-ethernet
<shelf/slot/port>
,andpressENTERtoaccesstheEthernetInterfaceConfiguration
prompt.
3. FromtheEthernetInterfaceConfigurationprompt,type
downlink,andpressENTER.
Thedownlinkcommandenablesdownstreamtreenetworkingontheselectedinterface.
Provision for Redundancy
Toprovisionforredundancy,completethefollowing:
NOTE
TomaketheGE4‐PortLineModuleinthe oddslotasth eactivemodule,
provisionitfirst.
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
redundancy <shelf/slot>.andpress
ENTER.
3. FromtheRedundancyConfigurationprompt,type
no shutdown,andpressENTER.
NOTE
RedundancyisnotfullyenableduntiltheevenslotisalsoInService.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
