ADTRAN Total Access 5000 Deployment Guide

65K510DEP08-1A 7-1
Section 7
EoF Provisioning
Scope of this Section
ThissectiondetailsthestepsneededtoprovisionanEoFapplicationusingtheTotalAccess
50008‐PortGigabitEthernet(GE8‐Port)LineModuleandtheNetVanta8044FiberNetwork
TerminationEquipment.
In this Section
Thissectioncontainsthefoll owingtopics:
Table 7-1. Section 7 Topics
Topic See Page
EoFOverview 7‐2
ProvisioningSummary 7‐3
ProvisiontheGE8‐PortLineModule 7‐4
ConfigureSubtendedHostInformation 7‐5
CreateanEVCCrossConnect 7‐6
LogOntotheNetVanta8044 7‐8
CreateanEVC 7‐9
CreateanEVCMap 7‐12
ProvisionPolicersintheNetVanta8044 7‐14
ProvisionMAC
AddressLimitingandAging 7‐17
DisableUnusedNetVanta8044Interfaces 7‐18
SavetheNetVanta8044Provisioning 7‐18
