ADTRAN Total Access 5000 Deployment Guide

65K510DEP08-1A G-1
Appendix G
BSM DS3/DS1 Layer 1 Tests
Scope of this Appendix
TheTotalAccess5000SystemRelease5.1supportsDS3andDS1testcapabilities.
In this Appendix
Thisappendixcontainsthefollowingtopics:
Table G-1. Appendix G Topics
Topic See Page
LoopbackDefinition G‐2
LineLoopback G‐2
PayloadLoopback G‐2
RemoteLoopback G‐3
DS3TestConfiguration G‐3
DS1TestConfiguration G‐5

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
