ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
F-10 65K510DEP08-1A
MAC Type - Broadcast/Multicast/Unicast
ThisattributematchestheMAC addresstypeoftraffictobeadmittedtotheEVCmap.Ifone
ormoreoftheseattributesareset,framesareadmittedintotheconnectedEVCifitmatches
anyofthetypesconfigured.Bydefault,anEVCmapignoresMACtypeintheclassification.

TableF‐9liststheMACtypes.
L2CP
ThisattributematchestrafficbasedonagroupofLayer2ControlProtocols(L2CP)desti‐
nationMACaddresses.Ifthisattributeisenabled,allL2CPframeslistedinTableF‐10are
classifedbytheEVCmap.
Example #1: Two CE-VLANs Mapped to Two EVCs
FigureF‐1illustratesanexampleoftwocustomerVLANsthatingressthenetworkelementon
acommonUNIportandmaptotwodifferentEVCs.CustomerVLAN1ismappedtotheEVC
withSVID101,andcustomerVLAN2ismappedtotheEVCwithSVID102.BothEVCs
can
resideonthesamephysicalinterfac e(forexample,bondinggroup),orboth EVCscanreside
ontwodifferentinterfaces.
Table F-9. MAC Type
Type MAC DA Description MAC DA Example
Broadcast All1s FF:FF:FF:FF:FF:FF
Multicast FirstoctetLSBis1 01:00:00:00:00:00
Unicast FirstoctetLSBisnota1 0A:C8:2C:DD:DD:DD
Table F-10. L2CP Frames
Control Protocol MAC Destination Address
STP/RSTP/MSTP 0180C2000000
Pause 0180C2000001
LACP/EFMOAM/LLDP/Slow
Protocol
0180C2000002
802.1x 0180C2000003
UndefinedBridgeAddresses 0180C2000004‐0E
AllBridges 0180C2000010
GMRP 0180C2000020
GVRP 0180C20000
21

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
