ADTRAN Total Access 5000 Deployment Guide

Appendix G, BSM DS3/DS1 Layer 1 Tests - DS1 Test Configuration
65K510DEP08-1A G-7
2. FromtheApplication prompt,starttheBERTbyperformingoneofthefollowing
commands:
•Type
test interface t1 <shelf/slot/port:channel> remote pattern
<pattern_type>
,andpressENTER.
•Type
test interface t1 <shelf/slot/port:channel> remote pattern
<pattern_type> loopback <lpbk_req_type> timeout <0-9999>
,andpress
ENTERtostartaDS1BERTtestandrequestaremoteloopback(atthecustomer
equipmenttowardtheTotalAccess5000)oftheDS1.
NOTE
•Valid<pattern_type>valuesare1in8,all0s,all1s,andqrss
NOTE
•Valid<lpbk_req_type>valuesarecsu,fdl,feac,andniu
3. FromtheApplication prompt,type
test interface t1 <shelf/slot/
port:channel> insert-error
,andpressENTERtoinjectabiterrorintothepattern.
NOTE
•Injectingabiterrorintothepatternisoptional
NOTE
•TheDS3BERTtestcanbestoppedbytypingno test interface t1
<shelf/slot/port:channel>,andpressENTER

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
