ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
1-4 65K510DEP08-1A
CAUTION
!
Duetocompliance certificationrequirements, only SFPs supplied by
ADTRANaretobeusedwiththeTotalAccess5000modules.ADTRAN
cannotcertifysystemintegritywhennonADTRANsuppliedSFPsareused.
1187250G1 EFMBondingProtectionModule BVL3ACUD__
1187450G1 AccessModuleInput/OutputDualChamp64‐PinPush‐
ThroughPanel(AMIO2‐CH64P)
BVPQADJM__
1187925L1/G1 AMIO1BlankPanel N/A
OtherComponents
1200633G4 NetVanta838 SIM5K10B__
1172839G1 NetVanta838EFMNTEEnhancedProtection VAMLC00B__
Table 1-2. Deployment Part Numbers (Continued)
Part Number Description CLEI

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
