ADTRAN Total Access 5000 Deployment Guide

65K510DEP08-1A vii
Icons
ThefollowingiconsareusedthroughouttheADTRANdocumentsuite:
Training
ADTRANofferstrainingcoursesonourproducts.Thesecoursesincludeoverviewson
productfeaturesandfunctionswhilecoveringapplicationsofADTRANproductlines.
ADTRANprovidesavarietyoftrainingoptions,includingcustomizedtrainingandcourses
taughtatourfacilitiesoratcustomersites.
Forinquiriesconcerningtraining,contactADTRAN:
TrainingPhone:
800‐615‐1176,ext.6303
TrainingFax:256‐963‐6217
TrainingEmail:training@adtran.com
deployment guide
installation guide
jobAid
reference guide
diagnostic guide
safety and regulatory
engineering guide
application guide
release notes
upgrade guide
user guide

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
