Rockwell Automation Publication 2198-UM004A-EN-P - October 2019 9

Chapter 1

Start

Use this chapter to become familiar with the Kinetix® 5100 drive system and

obtain an overview of installation configurations.

Topic Page

About the Kinetix 5100 Drive System 10

Typical Hardware Configuration 11

Motor and Auxiliary Feedback Configurations 12

Typical Communication Configurations 13

Typical Control Configurations 16

Safe Torque Off Configurations 19

Catalog Number Explanation 19

Agency Compliance 20
