10. Select and click a roll paper in the APaper Source list.
11. Make
sure the width of the loaded roll is displayed in the B Roll Width list—in this case, ISO A2/A3
(420.0mm).
Note
• If
the width of the roll loaded in the printer is not shown in B Roll Width, click L Printer In-
formation on the Main pane to update the printer information.
12. Make
sure C Page Size on the Page Setup pane shows the original size as specified in C Paper Size in the
Page Attributes dialog box—in this case, ISO A3.
13. Specify additional printing conditions.
For details on available printing conditions, see "Printer Driver Settings (Mac OS X) →P.404 "
Working With Various Print Jobs
>
Printing CAD Drawings
>
iPF825 Printing Line Drawings and Text (Mac OS X)
