Canon iPF825 - Printer Specifications

Printer Specifications
Specifications ............................................................................................................................................ 707
Print Area .................................................................................................................................................. 709
Specifications
Important
• The following values may vary depending on the operating environment.
Printer
Power supply 100–120 V AC (50/60 Hz), 220–240
V AC (50/60 Hz)
Power consumption During operation 190 W max.
Sleep mode 100–120 V: 5 W max.
220–240 V: 6 W max.
Off 1 W max. (*1 →P.707 )
Operating noise (*2 →P.707 ) During operation Approx. 52 dB (A) max. (6.8 bels or
less)
Standby Approx. 35 dB (A) max.
Operating environment Temperature 15–30°C (59–86°F)
Humidity 10–80%, non-condensing
Dimensions (W × D × H) Printer only 1,893 × 766 × 1,144 mm (74.5 × 30.2
× 45.0 in)
Printer and Stand (including Roll
Holder and Wheeled Output Stack-
er )
1,893 × 1,291 × 1,144 mm (74.5 ×
50.8 × 45.0 in)
Weight Printer and Stand (not including the
Printhead and Ink Tank )
Approx. 189 kg (416.7 lb)
Space for installation (W × D × H) Printer and Wheeled Output Stacker 2,293 × 1,837 × 1,500 mm (90.3 ×
72.3 × 59.1 in)
*1: The printer uses a trace amount of power even when turned off. To stop all power consumption, turn off the
printer and unplug the power cord.
*2: Calculation based on ISO 7779. Operating conditions: On the Main sheet of the printer driver, Media Type
> Plain Paper, Advanced Settings > Print Priority > Line Drawing/Text, and Print Quality > Standard.
Printing performance
Print method Bubblejet
Maximum resolution 2400 dpi horizontally (*1 →P.707 ) × 1200 dpi vertically
Printhead PF-03
Number of nozzles MBK: 5,120; Others: 2,560 each color
*1: Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Printer Parts
> Printer Specifications >
iPF825 Specifications
9
707
