Canon iPF825 - Printer Parts

Printer parts
Front .......................................................................................................................................................... 644
Back .......................................................................................................................................................... 646
Top Cover (Inside)
..................................................................................................................................... 647
Carriage ..................................................................................................................................................... 648
Ink Tank Cover (Inside) ............................................................................................................................. 649
Front
a.
Top Cover
Open this cover to install the Printhead, load paper, and remove any jammed paper from inside the printer as nee-
ded. (See "Top Cover (Inside).") →P.647
b.
Ejection Guide
Guides printed documents as they are ejected. Open this guide when loading a roll.
c.
Roll Holder Slot
Slide the Roll Holder into this slot.
d.
Roll Holder
Load the roll on this holder.
e.
Protective Cloth for Sheets
A cloth tray that catches ejected sheets.
Printer Parts
> Printer parts >
Front iPF825
