D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1084
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To add a user-defined OUI for a voice device:
DGS-3120-24TC:admin# config voice_vlan oui add 00-0A-0B-00-00-00 FF-FF-FF-00-
00-00
Command: config voice_vlan oui add 00-0A-OB-00-00-00 FF-FF-FF-00-00-00
Success.
DGS-3120-24TC:admin#
119-5 config voice_vlan ports
Description
This command is used to enable or disable the voice VLAN function on ports.
Format
config voice_vlan ports [<portlist> | all] [state [enable | disable] | mode [auto {[tag
|untag]}|manual]]
Parameters
ports - Specify a range of port to set.
<portlist> - Enter a list of ports used for the configuration here.
all - Specify that all the ports will be used for this configuration.
state - The voice VLAN function state on ports. The default state is disabled.
enable - Specify that the voice VLAN function for this switch will be enabled.
disable - Specify that the voice VLAN function for this switch will be disabled.
mode - The voice VLAN mode. The default mode is auto.
auto - Specify that the voice VLAN mode will be set to auto.
tag - When the port is working in auto-tagged mode, and learns about a voice device
through the device’s OUI, it will join the voice VLAN as a tagged member automatically.
When the voice device sends voice VLAN tagged packets, the Switch will change its
priority. When the voice device sends untagged packets, it will forward them to port’s
PVID VLAN.
untag - When the port is working in auto-untagged mode, and the port captures a voice
device through the device’s OUI, it will join the voice VLAN as an untagged member
automatically. When the voice device sends voice VLAN tagged packets, the Switch will
forward them according to the tag. When the voice device sends voice VLAN untagged
packets, it will assign priority and voice VLAN ID into this packet. When the Switch
receives LLDP-MED packets, it checks the VLAN ID, tagged flag and priority flag.The
switch should follow the tagged flag and priority setting. By default, the mode is auto
untagged.
manual - Specify that the voice VLAN mode will be set to manual.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
